Humanoid Robot · U1
The entry-level humanoid robot for AI and research: G1 platform with NVIDIA Jetson Orin NX (100 TOPS) and secondary development enabled. Distributed in Italy by Abra Robotics.
Request information about this product
G1 EDU Standard brings the G1 platform into the world of research: 8-core CPU paired with NVIDIA Jetson Orin NX 16GB (100 TOPS) for secondary development, with LIVOX MID-360 3D LiDAR and Intel RealSense D435i depth camera. 23 degrees of freedom and knee torque of 120 N·m for robust locomotion in real environments.
Indicative price, subject to EUR/USD exchange rate fluctuations — updated quote on request.
Technical datasheet
| Standing height | 1.320 mm |
| Width × Depth | 450 × 200 mm |
| Folded dimensions | 690 × 450 × 300 mm |
| Total weight | 35+ kg (battery included) |
| Materials | Aluminum alloy + high-strength technical plastics |
| Thigh + calf | 0.6 m |
| Max speed | 2 m/s |
| Max knee torque | 120 N·m |
| Max arm payload | ~3 kg |
| Total DoF | 23 |
| Leg (×2) | 6 DoF each |
| Arm (×2) | 5 DoF each |
| Waist | 1 DoF |
| Wrists | 0 DoF |
| Hands | 0 DoF (dummy) |
| Head | 0 DoF |
| Motors | Low-inertia inner-rotor PMSM |
| Bearings | Industrial cross-roller bearings |
| Encoders | Dual per joint |
| Computing unit | 8-core CPU + NVIDIA Jetson Orin NX 16GB (100 TOPS) |
| Secondary development | Yes |
| CPU | 8-core |
| Capacity | 9,000 mAh lithium 13S |
| Battery life | ~2 hours |
| Charger | 54V / 5A |
| Quick release | Yes |
| 3D LiDAR | LIVOX MID-360 |
| Depth camera | Intel RealSense D435i |
| Hands | Dummy hands without wrists |
| Tactile sensors | Not included |
| Microphones | 4 with noise/echo cancellation |
| Speaker | 5W stereo |
| Wi-Fi / Bluetooth | Wi-Fi 6 / BT 5.2 |
| Remote control | Included |
| OTA update | Yes |
| Cooling | Local air |
| Warranty | 18 months |
Engineering
G1 EDU Standard is the gateway to development: the 100 TOPS NVIDIA Jetson Orin NX 16GB module enables on-board deployment of control policies, vision and reinforcement learning, while LiDAR and depth camera provide the perception needed for autonomous navigation.
The modular architecture allows rapid upgrades and the aluminum alloy frame ensures rigidity without compromising weight, keeping the robot portable and operational in industrial and university environments.
Talk to an expert
Capabilities
The key capabilities of G1 EDU Standard — ready to use.
Jetson Orin NX 16GB with 100 TOPS: train and run your policies directly on the robot, without an external PC.
Knee torque of 120 N·m and dynamic control to walk, recover from pushes and handle uneven terrain.
LIVOX MID-360 LiDAR and RealSense D435i depth camera for mapping and autonomous navigation even in crowded spaces.
Financing
Most robotics projects are eligible for financing. We scout available incentives: Industry 4.0, PNRR, regional grants. We support you throughout the entire funding application process, giving you a clear picture of the actual cost.
| Hands and manipulation | |||
| Hand type | Dummy (no wrists) | Dummy (no wrists) | Dummy + wrists |
| Tactile sensors | — | — | — |
| Performance and computing | |||
| Total DoF | 23 | 23 | 28 |
| Knee torque | 90 N·m | 120 N·m | 120 N·m |
| Computing | 8-core CPU | Jetson Orin NX | Jetson Orin NX |
| Coverage | |||
| Warranty | 8 months | 18 months | 18 months |
| View product page | Request info | View product page | |
Technical data
The process
Three steps. No surprises. One point of contact from start to finish.
Fill in the form and describe your use case. We will respond within 12 hours with a preliminary assessment and, if needed, schedule a technical call.
We define together the model, accessories, any software configuration and the training path for your technical team.
Robot delivered, configured and operational in 2–4 weeks. Dedicated technical support throughout the warranty period and beyond.
Fill in the form, an ABRA consultant will get back to you within 12 hours.
